M9716B Programmable Electronic Load

Maynuo M9716B Programmable Electronic Load
Click an image to enlarge
Brand: Maynuo
RS-232 (Recommended Standard 232)

Retail price: $3,200.00

Depending on a destination shipping cost may vary.
See shipping page for international rates
or contact sales@tmatlantic.com

In stock, 1 left

Buy Add to cart

Maynuo M9716B programmable electronic load is a cost-effective solution for solar cell and power supply testing, battery and other DC power sources research with a supply voltage of up to 500 V, a load current of up to 120 A, and an absorbed power of up to 2400 W.

This programmable DC electronic load provides great performance, reliability and ease of operation with high functionality. This electronic load supports different stabilization modes (constant voltage, constant current, constant resistance, constant power) as well as a number of test functions (battery test, dynamic test, external trigger) which cover a wide range of applications.

Maynuo M9716B Electronic Load Features and Benefits

  • Operation modes: CV (constant voltage), CC (constant current), CR (constant resistance), CW (constant power), 2 combined modes: CC+CV, CR+CW
  • Protection for current, voltage, power, overheating, reverse polarity
  • Soft start function
  • Battery testing
  • Support for dynamic testing with rising and falling edge setting
  • External Trigger Support
  • Voltage drop compensation
  • List work
  • Automatic testing
  • USB / RS-232 control
  • VFD display



Input Rating Power 2400W
Current 0-120A
Voltage 0-500V
CC Mode Range 0-12A 0-120A
Resolution 1mA 10mA
Accuracy 0.05%+0.05%FS 0.1%+0.05%FS
CV Mode Range 0.1-19.999V 0.1-500V
Resolution 1mV 10mV
Accuracy 0.03%+0.02%FS 0.03%+0.05%FS
CR Mode (Voltage and current input value >=10% full measurement) Range 0.03-10K Oh 0.03-5K Oh
Resolution 16 bit 16 bit
Accuracy 0.1%+0.1%FS 0.1%+0.1%FS
CW Mode (Voltage and current input value >=10% full measurement) Range 0-2400W 0-2400W
Resolution 1mW 10mW
Accuracy 0.1%+0.1%FS 0.1%+0.1%FS
Voltage Measurement Voltage 0-19.999V 0-500V
Resolution 1mV 10mV
Accuracy 0.015%+0.03%FS 0.015%+0.05%FS
Current Measurement Current 0-12A 0-120A
Resolution 0.1mA 1mA
Accuracy 0.03%+0.05%FS 0.1%+0.08%FS
Power Measurement (Voltage and current input value >=10% full measurement) Power 100W 2400W
Resolution 1mW 10mW
Accuracy 0.1%+0.1%FS 0.1%+0.1%FS
Battert Test Battery Input: 0.5-120V; Max. Measurement: Capacity = 999AH; Resolution = 0.1mA; Time Range = 1s-16h
Dynamic Test Dynamic List: 0-25kHz; 2.5A/µs; T1&T2: 60µs-999s; Accuracy: +15% offset +10%FS
Current soft-startup Time 1ms; 2ms; 5ms; 10ms; 20ms; 50ms; 100ms; 200ms; Accuracy: +15% offset +10%FS
Short Circuit Current (CC) =13.2A =132A
Voltage (CV) 0V
Resistance (CR) =50mOhm
Temperature Operating 0~40°C
Nonoperating -10°C~70°C
Dimension WxHxD (mm) 207x428x453.5
Weight kg 31.6

Stantard Accessories

  • Power cord
  • User manual
