M9714B Programmable Electronic Load

Maynuo M9714B programmable electronic load is a cost-effective solution for solar cell and power supply testing, battery and other DC power sources research with a supply voltage of up to 500 V, a load current of up to 60 A, and an absorbed power of up to 1200 W.

This programmable DC electronic load provides great performance, reliability and ease of operation with high functionality. This electronic load supports different stabilization modes (constant voltage, constant current, constant resistance, constant power) as well as a number of test functions (battery test, dynamic test, external trigger) which cover a wide range of applications.

Maynuo M9714B Electronic Load Features and Benefits

• Operation modes: CV (constant voltage), CC (constant current), CR (constant resistance), CW (constant power), 2 combined modes: CC+CV, CR+CW
• Protection for current, voltage, power, overheating, reverse polarity
• Soft start function
• Battery testing
• Support for dynamic testing with rising and falling edge setting
• External Trigger Support
• Voltage drop compensation
• List work
• Automatic testing
• USB / RS-232 control
• VFD display

Specifications

Stantard Accessories

• Power cord
• User manual
