ATH-8125 Programmable Electronic Load

AKTAKOM ATH-8125 Programmable Electronic Load
Click an image to enlarge
Brand: AKTAKOM
RS-232 (Recommended Standard 232)

Retail price : $1,800.00

Depending on a destination shipping cost may vary.
See shipping page for international rates
or contact sales@tmatlantic.com

In stock, 2 left

Buy Add to cart

AKTAKOM ATH-8125 programmable electronic load is designed to work as a load when testing, configuring and adjusting power supplies, amplifiers and other electronic devices with a supply voltage of up to 500 V, a load current of up to 60 A, and an absorbed power of up to 1200 W.

AKTAKOM ATH-8125 programmable electronic load (analog of M9714B) provides great performance, reliability and ease of operation with high functionality. This electronic load supports different stabilization modes (constant voltage, constant current, constant resistance, constant power) as well as a number of test functions: battery test, dynamic test, external trigger.

Features

  • VFD display
  • Load operation modes: CV voltage regulation, CC current regulation, CR resistance regulation, CW power regulation, 2 combined modes: CC+CV, CR+CW
  • Protection for current, voltage, power, overheating, reverse polarity
  • Soft start function
  • Battery testing
  • Support for dynamic testing with rising and falling edge setting
  • External Trigger Support
  • Voltage drop compensation
  • List work
  • Automatic testing
  • USB / RS-232 control

InterfaceRS-232

Specifications

Input Rating Power 1200W
Current 0-60A
Voltage 0-500V
CC Mode Range 0-6A 0-60A
Accuracy 0.1mA 1mA
Resolution 0.03%+0.05%FS 0.03%+0.05%FS
CV Mode Range 0.1-19.999V 0.1-500V
Range 1mV 10mV
Accuracy 0.03%+0.02%FS 0.03%+0.05%FS
CR Mode (Voltage and current input value >=10% full measurement) Range 0.03-10K Oh 0.03-5K Oh
Resolution 16 bit 16 bit
Accuracy 0.1%+0.1%FS 0.1%+0.1%FS
CW Mode (Voltage and current input value >=10% full measurement) Range 0-1200W 0-1200W
Resolution 1mW 10mW
Accuracy 0.1%+0.1%FS 0.1%+0.1%FS
Voltage Measurement Voltage 0-19.999V 0-500V
Resolution 1mV 10mV
Accuracy 0.015%+0.03%FS 0.015%+0.05%FS
Current Measurement Current 0-6A 0-60A
Resolution 0.01mA 0.1mA
Accuracy 0.03%+0.05%FS 0.03%+0.08%FS
Power Measurement (Voltage and current input value >=10% full measurement) Power 100W 1200W
Resolution 1mW 10mW
Accuracy 0.1%+0.1%FS 0.1%+0.1%FS
Battery Test Battery Input: 0.1-150V; Max. Measurement: Capacity = 999AH; Resolution = 0.1mA; Time Range = 1s-16h
Dynamic Test Dynamic List: 0-25kHz; 2.5A/µs; T1&T2: 60µs-999s; Accuracy: +15% offset +10% FS
Current soft-startup Time 1ms; 2ms; 5ms; 10ms; 20ms; 50ms; 100ms; 200ms; 500ms; 1000ms; Accuracy: +15% offset +10% FS
Short Circuit Current (CC) =6.6A =66A
Voltage (CV) 0V
Resistance (CR) =50mOhm
Temperature Operating 0~40°C
Nonoperating -10°C~70°C
Dimension WxHxD (mm) 428x103.5x453.5
Weight kg 17.6
  • Power cord
  • User manual
