APS-1213 DC Power Supply 100V / 3A 1 Channel
APS-1213 DC Power Supply 100V / 3A 1 Channel
AKTAKOM APS-1213 DC power supply is widely used in debugging process, repair and laboratory research. Moreover it’s a perfect instrument for science investigation, college, factory, electronic appliance maintenance and etc. APS-1213 single channel bench power supply (analog of M10-QS1003) outputs smoothly adjustable stabilized DC voltage and stabilized current.
APS-1213 is a high precision regulated DC power supply with its continuously adjustable voltage output. Constant voltage and constant current are switchable automatically, and the current limit protection point can be set arbitrarily. In the constant current mode output current is continuously adjustable.
Features
- Constant voltage and constant current
- Additional USB 5V/2A output to charge mobile devices
- 2 LED displays output volt and amp
| Channels | 1 |
| Output voltage (V) | 100 |
| Output voltage display resolution | 0.1 V |
| Output current (A) | 3 |
| Output current display resolution | 0.001 A |
| Ripple and Noise | 10 mV |
| Display | 2 LED displays |
| Power supply | 220 V |
| Dimensions | 12.4 x 10.04 x 6.1 in / 315 x 255 x 155 mm |
Specifications
- Input voltage: 220VAC ~ 240VAC ±10% / 50Hz
- Output voltage: 0…100 V
- Output current: 0…3 A
- Ripple and noise: 10 mV RMS
- Protection: over current
- Display accuracy
- Volt indication: ±(0.5%Rdg+2 digits)
- Ampere indication: ±(0.5%Rdg+100 digits)
- Dimensions: 12.4 x 10.04 x 6.1 in / 315 x 255 x 155 mm
- Weight: 17.6 lb / 8 kg
Included accessories
- User Manual
- Power Cord
Frequently Asked Questions
May I use AKTAKOM power supplies to charge accumulators?
May I use AKTAKOM power supplies to charge accumulators?
|
|
AKTAKOM power supplies can’t be used for accumulator charging since it may cause the accumulator breakage (recharge, electrolyte boiling, extra pressure of the internal gas which will lead to the accumulator explosion). Accumulators should be charged with the current source which controls the accumulator voltage and regulates the charging current accordingly. When the required accumulator voltage is achieved such type of source simply stops the charging process, its name is a charging device.
Up
|
AKTAKOM APS-1213 es ampliamente utilizado en el proceso de depuración, reparación e investigación de laboratorio. APS-1213 emite una tensión de CC estabilizada suavemente ajustable y una corriente estabilizada. Además, es una fuente de alimentación perfecta para investigación científica, universidad, fábrica, mantenimiento de aparatos electrónicos, etc.
APS-1213 es una fuente de alimentación regulada de CC de alta precisión con su salida de voltaje continuamente ajustable. El voltaje constante y la corriente constante son conmutables automáticamente, y el punto de protección del límite de corriente se puede establecer arbitrariamente. En el estado de corriente constante, la corriente de salida es continuamente ajustable.
La estructura de la unidad es bastante compacta, el APS-1213 ocupa un área de trabajo muy pequeña. Otras características de esta fuente de alimentación incluyen un panel de aleación de aluminio, alto rendimiento, diseño moderno, etc.
Caracteristicas
- Tensión constante y corriente constante.
- Panel de aleación de aluminio.
- 2 pantallas LED de salida de voltios y amperios
